Sale price
Rs. 5,401.00
Regular price
Rs. 7,565.00
--54% OFF
Product Description
-
Conforms to IS 8623-1 & 3, IEC 61439-1 & 3
-
IK 08-for double door DBs, IK 09 for Double door DBs
-
Available in CRCA sheet steel, RAL9003, power coated
-
Ready to use DBs - Provided with 100A insulated phase bus-bar netural bar/s with shroud/s earth bar/s sticking saddles cement spill protector! colour-coded interconnecting wire set! cable ties! blanking plates and circuit identification label
-
With provision for 1. Modular Incomer -FP MCB/Isolater/RCCB/RCBO as incommer DP RCCB/RCBO as Sub Incomer and SP MCBs as outgoings
Product Specification
|
No of Way |
Modules |
Model No |
||
|
Incomer |
Sub Incomer |
Outgoing |
||
|
4 Way |
8 |
4+4+4 |
4+4+4 |
DBPSG004SD |
|
6 Way |
8 |
4+4+4 |
6+6+6 |
DBPSG006SD |
|
8 Way |
8 |
4+4+4 |
8+8+8 |
DBPSG008SD |
|
12 Way |
8 |
4+4+4 |
12+12+12 |
DBPSG012SD |
